Configuring Traffic Filters and Protocol Prioritization

314470-15.5 Rev 00 13-19

Specifying DLCIs as Match Criteria

To filter on a range of DLCIs, navigate to the match-ip-frame-relay prompt (for

example,

box; mct1 4/1; logical-line <MCT_line_no>; protocol-priority;

ip-outbound-filter

<filter_name>; match-ip-ip; match-ip-frame-relay) and enter

the following command:

pri-ip-fr-{dlci2byte | dlci3byte |dlci4byte} <byte_range>

byte_range specifies the PVC identification number (used by the frame relay

network to direct data) or ranges of numbers on which you want to filter outbound

traffic.

For the 2-byte DLCI address field, the valid values are 16 to 1007. Enter the

decimal number that the frame relay provider assigns.

For the 3-byte DLCI address field, the valid values are 1024 to 64511. Enter the

decimal number that the frame relay provider assigns.

For the 4-byte DLCI address field, the valid values are 131072 to 4194303. Enter

the decimal number that the frame relay provider assigns.

Specifying NLPIDs as Match Criteria

To filter on a range of NLPIDs, navigate to the match-ip-frame-relay prompt (for

example,

box; mct1 4/1; logical-line <MCT_line_no>; protocol-priority;

ip-outbound-filter

<filter_name>; match-ip-ip; match-ip-frame-relay) and enter

the following command:

pri-ip-fr-nlpid <nlpid_range>

nlpid_range specifies any number of network layer protocol identifiers

(NLPIDs). It can also specify ranges of NLPIDs.

Specifying the Action of Outbound Traffic Filters

For outbound traffic filters, you can specify different types of action:

• Filtering Actions

• Prioritizing Actions

• Dial Service Actions
