BayRS Version 15.5.0.0 Document Change Notice

2-2 314470-15.5 Rev 00

To reconfigure the trap port:

1. In the Configuration Manager window, choose Protocols > IP >

SNMP > Communities.

The SNMP Community List window opens.

2. Choose Community > Managers.

The SNMP Manager List window opens.

3. Choose Manager > Edit Manager.

The Trap Port and Trap Types window opens.

4. Type a new port number for the Trap Port parameter, then click on OK.

You can enter any port number on your Site Manager workstation, as long as

another application is not using that port.

You return to the Configuration Manager window.

5. Choose File > Save to save this configuration file.

See Chapter 3 in Configuring and Managing Routers Using Site Manager for

instructions on saving configuration files.

6. Choose File > Exit.

You return to the main Site Manager window.

7. Restart Site Manager according to the instructions in Chapter 1 of

Configuring and Managing Routers Using Site Manager

To make sure that Site Manager is able to listen to the port that you configured

in step 4, restart Site Manager using the

wfsm -e command or the Trap

Monitor using the wftraps -e command. For more information, about using

the

wfsm and wftraps commands with the -e option, see Appendix A in

Configuring and Managing Routers with Site Manager.

Note: You can also change the trap port on a PC by editing the

snmp-trap 162/udp snmp string in the Services file. From the Start menu,

choose Programs > Windows Explorer. Open the Services file and edit the

string snmp-trap 162/udp snmp. For example, to change the trap port from 162

to 779, enter

snmp-trap 779/udp snmp and reboot the PC. Site Manager PC

is then able to receive the traps from the router on port 779.
