BayRS Version 15.5.0.0 Document Change Notice

12-2 314470-15.5 Rev 00

You can use the Technician Interface to set the wfRipIntfDefaultRouteCost (RIP

default route cost) MIB attribute. This attribute interacts with the Site Manager

parameter Default Route Supply or BCC parameter default-supply in one of two

ways:

• If you select Enable for Default Route Supply or default-supply, RIP

advertises the default route cost you set for wfRipIntfDefaultRouteCost

attribute plus the default route learned from the network.

• If you select Generate for Default Route Supply or default-supply, RIP

advertises the default route cost you set for wfRipIntfDefaultRouteCost.

For additional information, see “Supplying a Default Route on an Interface” in

Configuring IP, ARP, RARP, RIP and OSPF Services.

With the Technician Interface, enter the following commands to set the

wfRipIntfDefaultRouteCost (RIP default route cost) attribute:

set wfRipIntfDefaultRouteCost <value>

value

is any integer from 0 through 15. The default value is 1.

commit

save config

You must have Manager access to issue a set command. The commit command

causes the changes you made to the configuration to take effect in active memory,

but not in flash memory. The

save config command saves changes to a

configuration file (config) and flash volume on the router.

Version 15.4.0.0

The following section describes how to enable the daylight savings time feature

for the router using the Technician Interface.

Setting Daylight Savings Time Using the Technician Interface

Daylight savings time is the time during which clocks are set one hour or more

ahead of standard time to provide more daylight at the end of the working day

during late spring, summer, and early fall. In the United States, we set the clock

ahead one hour at 2:00 am on the first Sunday in April and set the clock back one

hour at 2:00 am on the last Sunday in October.
