BayRS Version 15.5.0.0 Document Change Notice
6-4 314470-15.5 Rev 00
Adding a Tagged Circuit to an Unconfigured 10BASE-T or 100BASE-T
Interface
The following procedure describes how to add an 802.1Q tagged circuit to a
previously unconfigured 10BASE-T or 100BASE-T interface. The procedure
assumes that you are configuring the 802.1Q tagged circuit for IP routing. To
enable other routing protocols on an 802.1Q tagged circuit, see the appropriate
guide for that protocol.
Site Manager Procedure
You do this System responds
1. In the Configuration Manager window,
click on a 100BASE-T connector.
The Add Circuit window opens.
2. Click on OK. The Select Protocols window opens.
3. Choose VLAN, then click on OK. The Edit VLAN Interface Parameters
window opens.
4. Click on Add. The TAG1Q Parameters window opens.
5. Set the following parameters:
• VLAN Name
• Global VLAN Id
Click on Help to see the parameter
descriptions.
6. Click on OK. The Edit VLAN Interface Parameters
window opens. Note that 802.1Q tagged
circuits are displayed with a Vn extension.
7. Select the 802.1Q tagged circuit that you
are adding. Set the Protocol Type (hex)
parameter. Retain the default value for
connection to Nortel Networks
802.1Q-enabled devices.
8. Click on Apply and Done. You return to the Configuration Manager
window.
To add IP routing to the 802.1Q tagged circuit:
9. Choose Circuits.
10. Choose Edit Circuits. The Circuit List window opens.
11. Select the 802.1Q tagged circuit.
Note that 802.1Q tagged circuits are
displayed with a Vn extension.
