Configuring Ethernet, FDDI, and Token Ring Services
314470-15.5 Rev 00 6-5
Adding a Tagged Circuit to an Existing 10BASE-T or 100BASE-T
Interface
To add an 802.1Q tagged circuit to an existing 10BASE-T or 100BASE-T
interface, complete the following tasks:
12. Click on Edit. The Circuit Definition window opens.
13. Choose Protocols.
14. Choose Add/Delete. The Select Protocols window opens.
15. Select IP and click on OK. The IP Configuration window opens.
16. Enter an IP address and subnet mask and
click on OK.
The Circuit Definition window opens.
17. Choose File.
18. Choose Exit. The Circuit List window opens.
19. Click on Done. You return to the Configuration Manager
window.
Site Manager Procedure
You do this System responds
1. In the Configuration Manager window,
click on a 10BASE-T or 100BASE-T
connector.
The Edit Connector window opens.
2. Click on Edit Circuit. The Circuit Definition window opens.
3. Choose Protocols. The Protocols menu opens.
4. Choose Add/Delete. The Select Protocols window opens.
5. Choose VLAN, then click on OK. The Edit VLAN Interface Parameters
window opens.
6. Click on Add. The TAG1Q Parameters window opens.
7. Set the following parameters:
• VLAN Name
• Global VLAN Id
Click on Help to see the parameter
descriptions.
Site Manager Procedure (continued)
You do this System responds
