BayRS Version 15.5.0.0 Document Change Notice

13-2 314470-15.5 Rev 00

The following sections describe how to use the BCC to enable protocol

prioritization and configure outbound traffic filters.

You implement protocol prioritization by applying an outbound traffic filter that

includes a prioritizing (priority queue) action. This type of outbound traffic filter

is called a priority filter. The next section describes how to edit protocol

prioritization parameters that affect the way priority filters work.

Configuring Protocol Prioritization

To configure priority queues with default values, do the following:

1. Configure protocol priority on the circuit, as described in this section.

2. Apply outbound traffic filters with prioritizing action to the circuit, as

described in “Creating Outbound Traffic Filters,” later in this chapter.

To configure protocol priority, navigate to the interface prompt (for example, box;

ethernet/2/1) and enter:

protocol-priority

For example, the following command configures protocol priority on connector 1

of an ethernet module installed in slot 2:

ethernet/2/1# protocol-priority

protocol-priority/ethernet/2/1#

Displaying Protocol Priority Parameter Values

To view the current values of the protocol-priority parameters, navigate to the

protocol priority prompt (for example, box; ethernet/2/1; protocol-priority) and

enter:

info

Topic Page

Configuring Protocol Prioritization

13-2

Customizing Protocol Prioritization 13-3

Creating Outbound Traffic Filters 13-8
