BayRS Version 15.5.0.0 Document Change Notice

21-4 314470-15.5 Rev 00

keepalive-retry-timeout-<value>

value is an integer between 1 and 32766, inclusive. It represents the number of

seconds that the router waits between sending successive GRE keepalive

messages from the GRE tunnel’s local end point to one of its remote end points.

For example, the following command sequence changes the keepalive retry

timeout interval for the remote tunnel austin to 20 seconds and verifies the

change:

remote-endpoint/austin# keepalive-retry-timeout 20

remote-endpoint/austin# info

address 192.168.2.4

keepalive enabled

logical-ip-address 0.0.0.1

logical-ipx-address 000000000001

name austin

keepalive-retries 3

keepalive-retry-timeout 20

state enabled

Using Site Manager

To change the default value of the GRE keepalive retry timeout interval for a

remote tunnel end point, complete the following tasks:

Site Manager Procedure

You do this System responds

1. In the Configuration Manager window,

choose Protocols.

The Protocols menu opens.

2. Choose IP. The IP menu opens.

3. Choose GRE. The GRE Create Tunnels List window

opens.

4. Click on Remote Conn. The GRE Remote Connections List

window opens.

5. Select the remote tunnel end point for

which you want to set the keepalive retry

timeout interval value from the list.
