BayRS Version 15.5.0.0 Document Change Notice

18-6 314470-15.5 Rev 00

To specify the fragment size for PPP multilink multiclass using Site Manager,

perform the following tasks:

Site Manager Procedure

You do this System responds

1. In the Configuration Manager window,

choose Protocols.

The Protocols menu opens.

2. Choose PPP.

3. Choose Interfaces. The PPP Interface List window opens.

4. Click on the interface for which you want

to set the fragment size.

5. Click on Classes. The PPP Multiclass Classes window

opens for the selected interface. (only if

Multilink MultiClass is enabled for the

selected interface)

6. Click on the class for which you want to

set the fragment size.

7. Set the Fragment Size parameter. Click

on Help or see the parameter descriptions

beginning on A-26

8. Click on Apply.

9. Repeat steps 6 through 8 for each class

for which you want to set the fragment

size.

10. Click on Done. You return to the PPP Interface List

window.

11. Click on Done. You return to the Configuration Manager

window.
