Configuring IP, ARP, RIP, RARP, and OSPF Services
314470-15.5 Rev 00 8-9
ospf# rfc3101-fwd-addr-compatibility enable
ospf#
Using Site Manager
To enable or disable RFC 3101 compatibility on the router, complete the
following tasks:
Configuring the Not-So-Stubby Area (NSSA) Forwarding Address
Once you enable RFC 3101 compatibility on the router, you must specify the IP
address to be used as the new ASE forwarding address for the NSSA. You can
specify this address using the BCC or Site Manager.
Using the BCC
Before you can configure a not-so-stubby area (NSSA) forwarding address, you
first must enable the
nssa-default-originate parameter.
Site Manager Procedure
You do this System responds
1. In the Configuration Manager window,
choose Protocols.
The Protocols menu opens.
2. Choose IP. The IP menu opens.
3. Choose OSPF/MOSPF. The OSPF/MOSPF menu opens.
4. Choose Global. The Edit OSPF Global Parameters
window opens.
5. Set the Rfc 3101 Compatibility Enable
parameter. Click on Help or see the
parameter description on page A-22
.
The value you chose appears in the Rfc
3101 Compatibility Enable field.
6. Click on OK. You return to the Configuration Manager
window.
Note: To configure this parameter, you first must enable the origination of a
type 7 default route by the AS boundary router.
